Automatic Detection and Monitoring of Insect Pests

1.Introduction to Automatic Detection and Monitoring of Insect Pests

Automatic Detection and Monitoring of Insect Pests can automatically detect and monitor many types of pests, providing important decision support information for pest management.Our company's new automatic target monitoring system is based on edge computing, which can realize targeted pest trapping.It can be classified and counted for different insect situations, count the number of insect situations in different time periods, take photos of the targets, and send pictures regularly according to the background settings.Mainly used in parks, forest farms, orchards.

2.Automatic Detection and Monitoring of Insect Pests Technical Indicators

1.The system adopts a solar power supply system and realizes automatic shutdown of the system during rainy days; the host must be able to work normally in harsh weather for a long time, working temperature: -20℃-70℃; working humidity: 0-95%

2.Target pests are collected through sexual attractants.The equipment can be divided into: Lepidoptera, Coleoptera and other automatic detection and reporting systems for target pests.

3.The height of the trapping and counting device can be adjusted according to the height of the crop.

4.Automatically eliminate non-target pests

5.Counting interval ≦0.1 seconds

6.It has the function of remote automatic data transmission, and the data covers: pest number, trapping time, GPS information, temperature and humidity, etc., and the following reporting methods can be set remotely:

① Automatic upload based on pest threshold

② Automatic upload at fixed time

③At any time point, remote send commands are automatically uploaded

7.Upload data can be reported to the user's designated address in real time, and can realize the reception of multiple clients on mobile phones and computers.

8.The main circuit board has no less than 8 environmental factor expansion interfaces and no less than 4 trap expansion interfaces.

9.The host has remote power switch, remote diagnosis and maintenance functions for equipment failures, remote reminder of equipment abnormalities or faults, and time reminder of sexual inducement expiration replacement

10.It can be configured with integrated photo shooting + counting function and control system equipment
