Anchor cable dynamometer

1.Anchor cable dynamicometer product overview

Anchor cable dynamometer is an essential instrument in the field of construction and engineering, designed to measure the changes in stress applied to the anchor bolt.This series of Anchor cable dyestuffs is mainly used to monitor the stress changes of anchor cables and anchors in geotechnical engineering, civil building structures and underground cave rooms. Anchor cable dynamicometer adopts imported high-quality steel strings, advanced manufacturing and installation methods, and fully waterproof sealing structure, with high sensitivity, high reliability and long-term stability.

2. Anchor cable dynamicometer application scenario

Bridges, tunnels, rail transit, water conservancy

3. Features of Anchor cable dyestuff

1.Use imported steel strings, stable temperature performance and long service life

2. Built-in thermistor temperature sensor for easy temperature compensation

3. High resolution, strong anti-interference ability, and sensitive to concentrated loads

4. Design of fully waterproof seal structure

4. Technical parameters of Anchor cable dynamicamometer

Range: 500kN, 1000kN, 2000kN, 3000kN, 4000kN

Resolution: 0.1%FS

Temperature range: -20℃~+70℃

Temperature measurement accuracy: ±0.5℃

Note: Anchor cable dynamicamometer is not fixed, each model has it, determined according to the anchor cable specifications
