Fixed inclinometer

1.Introduction to Fixed inclinometer

Fixed inclinometer An instrument used to measure the angle of slope/inclination and the rise/fall of an object relative to gravity.This type of Fixed inclinometer is a Fixed inclinometer with a large range, ultra-low power consumption, and ultra-high precision.It is mainly used to measure the changes in the deep displacement (angle) in the inclinometer in the inclinometer for a long time.The magnetometer water meter measurement system intelligently recognizes parameters, intelligent fault diagnosis, and seamless connection between cloud platform and mobile phones.

2.Fixed inclinometer product features

1.Accurately measure the inclination angle, acceleration, temperature and voltage of the three-axis;

2.Ultra-low power consumption reduces the burden on the power supply system;

3.Extremely large ranges, which can be used in ultra-large deformation monitoring application scenarios;

4.The communication interface adopts a standard RS485 interface, which can be directly connected to DTU, serial port server or other collectors.It is very convenient to integrate and can be connected to 128 units in parallel;

5.The communication protocol adopts the standard MODBUS protocol, which facilitates protocol docking and can freely cut required data;

6.Built-in temperature measurement unit, which automatically performs temperature compensation, reduces the sensor temperature drift;

7.Powerful interface protection, anti-power reverse connection function;

8.Excellent lightning protection and anti-static performance (60kV/600W);

9.Sealing level: IP68 dustproof and waterproof level;

10.Water pressure resistance: 2Mpa (can be used for a long time underwater for 200 meters);

III.Fixed inclinometer industry application

Landslide monitoring; foundation pit monitoring; road slope; tailings monitoring;

4.Fixed inclinometer technical parameters
