Rainfall Simulator

1.Rainfall Simulator product overview

Rainfall Simulator simulates real rainfall conditions in nature and is used in soil science and hydrology to study the response of soil to rainfall.Rainfall Simulator is one of the supporting auxiliary equipment for the artificial automatic simulation rainfall hall developed by our company.It is a large artificial simulated rainfall device developed to meet the outdoor soil and water conservation simulation natural rainfall experiment.Through years of actual rainfall application and many on-site summary and improvement, the equipment has developed from the original first and second generation products to the current third-generation fully automatic touch product of full intelligent control.The technical indicators of this product are fully in line with the specifications of the "SL419-2007 Soil and Water Conservation Test Regulations".Now this product uses the leading domestic full touch screen control, which is more convenient and simple.The rainfall nozzle is completely imported and manufactured by SPAYING SYSTEMS company in the United States, FULLJET rotary spray nozzle, made of stainless steel, which can effectively ensure the uniformity of rainfall and the particle size range of raindrops.

2.Rainfall Simulator application field

This equipment has a wide range of applications.The existing soil erosion area in the country is 3.66 million square kilometers and needs to be used to apply simulated rainfall devices, establish soil erosion databases in various places, and provide scientific basis for planning, design, and soil and water conservation supervision and law enforcement; provide accurate experimental data for the Water Conservancy and Soil Conservation Research Institute and other units and related industry planning, design, and survey research institutes engaged in the preparation of soil and water conservation plans.It is also widely used in designated farmland sprinkler irrigation, urban landscaping sprinkler irrigation, highway green belt sprinkler, construction site dust sprinkler irrigation, etc.

3.Rainfall Simulator product features

1.Mainly used for experimental needs of various indoor rainfall halls or large outdoor rainfall experimental fields.

2.The overall installation adopts a quick-install modular design.The unique bracket self-locking deployment mechanism ensures the quickness of bracket assembly.The pipe fitting connectors are connected by plug-and-play quick-connection.

3.Made of all stainless steel, beautiful appearance, strong and durable.

4.The system provides its own power generation/hydropower/rain volume mediation.

5.The original imported undershot rainfall nozzle of the United States SPAYING SYSTEMS can make the energy of raindrops falling to the ground similar to natural rainfall.

6.The entire product is designed, researched and developed according to military-grade standards, and its service life can reach more than 20 years.

7.Various rainfall setting modes: cumulative rainfall mode, cumulative time mode, intermittent rainfall mode, cumulative rainfall and time dual control mode, and time-controlled segmented multi-rain mode.

8.Various rainfall combinations of nozzles: mist-shaped rain sprinkler, small rain sprinkler, medium rain sprinkler, heavy rain sprinkler, and heavy rain sprinkler.

9.High-precision rainfall information statistics, using advanced electromagnetic water flow information collection module, the accumulated rainfall can be directly calculated in 1 second, and the resolution can reach 0.1mm.

10.Built-in large-capacity data storage system, which can store up to 100,000 historical data, and can automatically generate rainfall curve reports.

11.Supports wired and wireless dual communication modes.Wired communication includes RS485, RS232, USB, and wireless communication includes LORA digital radio station, Bluetooth communication, and 4G communication.

12.Simulated environment cloud monitoring, you can query and configure simulated rainfall data in real time through the mobile WeChat APP or remote server computer.

4.Rainfall Simulator technical indicators
