Scattered radiation sensor

Scattered radiation sensor can continuously determine the intensity of scattered radiation in the sky and is widely used in meteorological stations and scientific departments.Scattered radiation sensor consists of two parts: the total radiation meter and the halo ring. The function of the halo ring is to ensure that it can continuously block the direct sun radiation from sunrise to sunset. The halo ring consists of a halo ring, a ruler, a screw adjusting spiral, a bracket, and a chassis. The width of the halo ring is 65mm and the diameter is 400mm. It is fixed on the screw adjustment spiral of the ruler, and the latitude scale and declination scale are engraved on the ruler. The ruler and bracket are fixed to the chassis and should be fixed according to the geographical latitude of the shooting location.

Scattered radiation sensor product parameters:

Test range: 0～2000W/㎡

Resolution 1W/㎡

Accuracy ±5%

Sensitivity: 7～14μV/wm-2

Response time: ≤35 seconds (99%)

Internal resistance: about 350Ω

Spectral range: 0.3~3μm.years

Stability: ±2%

Cosine response: ≤±7%

(When the sun's height angle is 10°) Azimuth response error: ≤5%

(When the sun's height angle is 10°)

Working ambient temperature: -40℃~+50℃
