Handheld Weather Station

1.Introduction to Handheld Weather Station

Handheld Weather Station is used for portable monitoring of outdoor weather conditions, with five meteorological elements: wind direction, wind speed, atmospheric pressure, temperature, and humidity.Handheld Weather Station is a movable meteorological observation instrument that is easy to carry, simple to operate, and integrates multiple meteorological elements.The system uses precision sensors and smart chips, which can accurately measure the five meteorological elements of wind direction, wind speed, atmospheric pressure, temperature and humidity at the same time.The built-in large-capacity FLASH storage chip can store meteorological data for at least one year; it is a universal USB communication interface, which connects to the USB disk to export data, which facilitates users' further processing and analysis of meteorological data.

Handheld Weather Station can be widely used in meteorological, environmental protection, airports, agriculture and forestry, hydrology, military, warehousing, scientific research and other fields.

2.Functional features of Handheld Weather Station

2.1-inch screen LCD displays temperature, humidity, wind speed, and air pressure value;

A specially made wind dial (16 orientations) and pointers are used to indicate real-time wind direction;

Large-capacity data storage, up to 40,000 meteorological data can be stored (data recording interval can be set between 1 and 60 minutes);

Universal USB communication interface, convenient for USB data download;

Only three No.5 dry batteries are required to be powered; low-power design, long-term standby;

The structure is scientific and reasonable, and is easy to carry.

3.Technical parameters of Handheld Weather Station

4.Precautions for using Handheld Weather Station

1.It is recommended to clean up the data storage every time the computer needs to start, to prevent the large amount of data when exporting the currently required data, resulting in too long time.

2.It is recommended to export the data content in the weather station in a timely manner after use.

3.Please read this manual carefully before use to ensure that the sensor must be inserted into the corresponding sensor interface and the battery direction is correct;

4.When the battery level is insufficient on the instrument, please change the battery in time to prevent the battery from leaking and damaging the instrument;

5.Prevent chemical reagents, oils, dust, etc.from directly invading the sensor.Do not use it for a long time under condensation or extreme temperature environments.Do not cause cold or hot impact;

6.The instrument is a precision device.Users should not disassemble it by themselves when using it to avoid damaging the product;

7.Please save the verification certificate and certificate of conformity and return with the product during maintenance.
