Aquaculture virus detection

Aquaculture virus detection is the most widely used diagnostic tool for viral infections in marine aquaculture and is used for on-site detection in aquaculture.Aquaculture virus detection has the characteristics of simple use, easy operation and easy control.It can quickly detect viruses in the body of aquatic products such as fish and shrimp, and achieve timely diagnosis and control.

1.Features of Aquaculture virus detection instrument

1.Small size, light weight, easy to carry.Easily meet the needs of going out experiments.

2.Built-in 7-inch high-definition capacitor screen PDA, touch screen operation, simple and fast.

3.Marlow's high-quality Peltier refrigeration plate, combined with Germany's high-end PT1000 temperature sensor and the temperature control mode of the electrical resistance heating compensation edge, the maximum temperature increase speed is 7℃ and the maximum temperature decrease speed is 5℃, greatly shortening the experimental time.

4.The 3s fast lighting mode of the whole plate ensures consistency of the hole position of the experimental results.

5.Concise and intuitive software guidance, easily enable detection experiments.

2.Aquaculture virus detection application field

Basic scientific research

Pathogen detection

Adulterated meat products

Genetically modified test

Food safety testing

Drug development and rational use of medicine

Gene expression

Water monitoring

3.Technical parameters of Aquaculture virus detection

Sample capacity: 8x0.2ml, support 8-connection tube

Suitable consumables: Common transparent PCR consumables, 8x0.2ml drain pipe, 0.2ml single tube

Reaction system: 5-120ul reaction mode system

Heating/refrigeration module: imported semiconductor thermoelectric module

Temperature control range: 4°C-99°C

Average cooling rate ≥2°C/sec

Temperature control accuracy: ≤±0.1°C

Temperature uniformity: ≤±0.2°C

Number of temperature control areas: multiple points (2 points)

Number of gradients: 0

Gradient temperature range: None

Gradient hole number: None

Exciting light source: maintenance-free LED

Excitation light wavelength range: 400-700nm

Detection components: imported photodetector

Number of detection channels: standard 1 channel (FAM), high-end (optional) (FAM, VIC)

Applicable dyes and probes: FAM/SYBR Green I, VIC/HEX/CY3 (optional), ROX/Texas Red (optional), Cy5, TAMARA (optional)

Software functions: fluorescence quantitative PCR system software; real-time amplification reaction curve function; real-time reaction curve display of specific specimens; data analysis function;

Automatic determination function of Yin and Yang results; graphical display function.

Noise: <45 dB

Screen size: 7 inches (HD)

Touch screen: capacitive

External USB: Supports data import and export

Heat cover: automatic pressure adjustment

Appearance size: 290(W)*308(L)*130(H)

Box size: 75 length * 38 width * 19 height cm

Net weight: about 3Kg
